milling spindle F200PAEF1804016SA36KJ_10011

2SP1

Standard motor milling spindles from the 2SP1 series are motor spindles that can be ordered from our catalog.They are designed for high torques and can therefore be used for both roughing and finishing.

milling spindle F200PAEF1804016SA36KJ_10011

Technical data

Series
2SP1
Appli­cation
milling spindle
Inter­face
HSK-A63
Shaft clamp
no
Release unit
pneumatic
Rotary feed-through
Yes
Rotary transducer
Yes
Maximum speed
18.000
Nominal speed
4.300
Nominal power
15
Nominal torque
34,0
Motor type
synchronous
Diameter
200,0
Length
835
Bearing lubrication
grease
Datasheet CAD Download
Overview
